KAFFELOGIC NANO 7 COFFEE ROASTER

Roaster Type: Home or Professional, countertop, customizable electric coffee roaster with variable airspeed, fluidized air (fluid bed roaster)

Training/Set Up:  No training required, easy to set up and roast right out of the box

Automation System: Dual profiles, adjustable temperature and adjustable airflow

Temperature Control: PID control with the unique Kaffelogic look-ahead and gain scheduling system, fully user programmable

Recommended Batch Size: 80-100g roasted (100-120g green), or, with BOOST add-on, down to 50g and up to 200g green coffee .

Green Coffee: Use any green coffee in the Kaffelogic.  When ordering with a Kaffelogic, green coffee is discounted by 15% (discount will automatically apply in cart).  Additionally, Showroom Coffee Kaffelogic customers will receive a lifetime coupon code for 5% off green coffee. Both green coffee discounts exclude Bag Ends.

Roast Time (typical): 10 mins

Cool Down Time (typical): 4 mins

BOOST Kit Add-On: The optional BOOST kit will transform your Kaffelogic Nano 7 into a multi batch capacity machine that allows you to roast a wider range of batch sizes, from a minimum 50-60g to a maximum 180-200g green coffee (results may vary depending on different factors including coffee type, processing method and roast levels). The BOOST kit includes a lathed anodized aluminum chamber extension with tensioning ‘legs,’ a Studio Software Activation Code (SAC) and a measuring/ dosing cup.  The chamber extension is used when roasting volumes greater than 100-120gms whilst the SAC automatically modifies the fan and heat profiles on your selected profile to suit whichever batch size you are roasting.  The BOOST IS $160 if purchased with the Kaffelogic, or $180 as a standalone purchase.

Heater: 1400 W

Motor: Brushless DC

Power Supply: 115-120v / 50-60hz

Weight: 7.9 lb / 3.6 kg

Dimensions: 4.9 in x 4.9 in x 11 in  (125 mm x 125 mm x 280 mm) WxDxH base unit, height with chaff collector 16.9 in (430 mm) (BOOST kit does not increase height)

Materials: Case – Powder coated steel, Plastic fittings – Nylon PA66, Roast chamber – Aluminum

Safety: continuous monitoring with full shutdown on fault detection

ROAST TRACKING/CONNECTIVITY: Track/profile/edit roasts with Kaffelogic Studio software.  Import and export from Artisan or Cropster  – connected by USB.

There is absolutely no need for you to use Studio so long as you find the Kaffelogic 12 core profiles are meeting your needs. If that is the case, just select the appropriate profile and enjoy the coffee. However, if you develop the interest in the future you can start downloading, studying, and modifying additional profiles, and Studio will then become your coffee roasting hub for the Nano 7.

On the other hand, if you are buying a Kaffelogic specifically because you want to modify and create roast profiles, then Studio will be your main profile management tool from the get go.

Ventilation: No special ventilation is required, however  we recommend the use of a stove hood in your roasting area.  The Kaffelogic roaster produces about the same amount of smoke as frying food. The smoke is barely visible and a domestic stove hood extractor fan is plenty sufficient for removing it from the kitchen. A good extractor fan will eliminate all smell; a less effective fan will leave you with a pleasant whiff of roasting coffee. If you do not have an extractor fan we recommend running a domestic air purifier in the same room. Otherwise you will notice quite a strong smell of roasting coffee. Some people like it, others are not so keen on it. Without some form of ventilation or air filter we recommend roasting only one batch at a time. You can also roast outdoors!

Warranty: 2 year parts warranty. Some repairs may be done by the user, others may be performed by technicians at Showroom Coffee in New York.  Shipping is free for the first 30 days (from receipt of roaster by customer) on parts shipped to the customer or the unit shipped to Showroom for repair.  After 30 days, customer is responsible for shipping.  After repair of a unit by Showroom technicians, Showroom pays return shipping.  Parts and service warranty covers malfunction due to manufacuter’s defect and does not cover damage due to user error or other misuse.

Shipping Weight: 17 lbs

Shipping Dimentions: 22 x 16 x 6 in (l x w x h)

Certification: UL (120v units) or CE (220v units)

—

SHIPPING OR PICKUP:  Kaffelogic shipping is free for all customers in the US and Mexico.  We ship Kaffelogic to customers in the US from our warehouse in Brooklyn, New York, via UPS Ground, or via an express option if chosen by the customer.  We ship to customers in Mexico via a courier to most town centers (customer picks up from paqueteria location). Shipping Kaffelogic is free to customers in Mexico and includes customs clearance and duty.

For shipping to other countries, please contact us.

FINANCING: We are proud to offer financing to both individuals and businesses. Individuals can finance their purchases through Affirm, already integrated into Showroom’s checkout process.  Commercial businesses may finance their roaster through Partners Capital.  For more infomation on both types of financing, pleae visit our Roaster Financing Page.

KAFFELOGIC STUDIO ROAST PROFILE SOFTWARE

Kaffelogic Studio is the roaster’s profile management software. It is available for free download and allows you to view logs as well as modify and design profiles.

There is absolutely no need for you to use Studio so long as you find the Kaffelogic 12 core profiles are meeting your needs. If that is the case, just select the appropriate profile and enjoy the coffee. However, if you develop the interest in the future you can start downloading, studying, and modifying additional profiles, and Studio will then become your coffee roasting hub for the Nano 7.

On the other hand, if you are buying a Kaffelogic specifically because you want to modify and create roast profiles, then Studio will be your main profile management tool from the get go.

Viewing Logs

When you use the Nano 7, the roast is automatically logged on the internal memory. This log can be viewed using Kaffelogic Studio when connected with the included USB cord. The log shows the roast profile curve with the actual temperature curve from the roast superimposed. In addition there are several channels of information that help assess how the beans responded to the profile, including rate of rise and heater power.

Editing Profiles

Kaffelogic Studio has an easy to use curve editor that allows you to quickly draw roast profile curves exactly as you want them. There are also a number of settings that can be adjusted, including fan profile and changes that can be made to the roaster’s behavior at specific times during the roast. These settings are organized into four levels of difficulty, so that the beginner can select an appropriate set of controls without being overwhelmed at the start. Whether you want to dabble with making small tweaks to our existing core profiles, or go full noise and start developing roast profiles from scratch, Kaffelogic Studio is the right tool for the job.

Intuitive Workflow

With Kaffelogic’s Connect system, roast iteration is super easy. Connect to a laptop to examine the log, and cup the coffee. Extract the profile from the log to make changes. Then save the edited profile  back to the roaster, and repeat the cycle. In this way customized profiles can be quickly developed where you are responding to what the beans actually did in the last roast.

Powerful Import and Export Feature

Kaffelogic Studio has been built to facilitate using the Nano 7 as a sample roaster for commercial production roasts. It can import and export in a number of formats including Artisan, Cropster, Sonofresco™, and Ikawa™ (import only). And because production roasters have different bean temperature probes it also has temperature and time conversions that can be automated, tuned, and saved to enable near instant transfer of a Kaffelogic profile onto your production roaster. And if that seems a bit complicated, our roast consultant can assist with training.

Free Download

Download Kaffelogic Studio for free, whether or not you are a Kaffelogic customer. It’s not as much fun if you don’t have the roaster, but you are nevertheless welcome to try it before you buy your roaster.
